KEY FEATURES
• Type: Mixer
• Balanced microphone input/balanced line input (MIC/LINE IN): 32 XLR / 32 TRS
• Stereo input (STEREO IN): 2 Stereo RCA / 1 AUX
• USB/Bluetooth/PC: 1.0
• Unbalanced AUX bus outputs (AUX SEND): 10 XLR
• Headphone output (PHONES): 1 TRS
• Main speaker output (MAIN OUT): 2 XLR / 2 TRS
• Input gain/pre-amp level control: -32-10dB (max +29dB)
• Low-cut filter (CUT): 12dB/24dB, 20Hz-20kHz
• Microphone input equalizer (EQ MIC IN): 5-band "20Hz--20kHz" +/-12dB"
• Equalizer Stereo Inputs (EQ STEREO IN): 5-band "20Hz--20kHz" +/-12dB
• Main Output EQ (EQ MAIN): 30-band "20Hz--20kHz" +/-12dB
• Faders (Faders): 33 pcs / 100mm
• Effects Bus (FX): 4
• Phantom Power for Mic Inputs (PHANTOM): 48V
• Power Consumption: 150W
• Power Supply: AC100-240V
