KEY FEATURES
• Type: Array element with constant directivity
• Frequency range: 50 - 20,000 Hz (±10 dB), 60 Hz - 18,000 (±3 dB)
• Sensitivity: LF: 96 dB, HF: 112 dB
• Coverage angle: 100° x 15°
• Nominal impedance: LF: 16 ohms, HF: 16 ohms
• Sound pressure level SPL: LF: 123 dB, 129 dB peak, HF: 131 dB, 137 dB peak
• Drivers: LF: 1x14" 75 mm voice coil, ferrite magnet HF: 1x3" 75 mm voice coil, neodymium compression magnet
• Connection method: Bi-amp, 2xNeutrik NL4x2 / LF 1+1, HF 2+2
• Nominal power: LF: 500 W, HF: 80 W (AES)
• Enclosure: 15 mm birch plywood
• Enclosure finish: Black water-based paint
• Grille: Black steel grille, acoustically transparent fabric
• Dimensions: 750 x (382 x 260) x 447.5 mm
• Weight: 30 kg
