KEY FEATURES
• Type: Line array element
• Frequency response: 60 - 20,000 Hz (±10 dB), 70 Hz - 18,000 (±3 dB)
• Sensitivity: 104 dB
• Coverage angle: 100° x 10°
• Nominal impedance: 8 ohms
• Sound pressure level SPL: 132 dB, 138 dB peak
• Drivers: LF: 2x9" 65 mm voice coil, ferrite magnet HF: 1x3" 75 mm voice coil, neodymium compression magnet
• Connection method: Full Range, 2xNeutrik NL4x2 / 1+1-
• Nominal power: 800 W (AES)
• Enclosure: 15 mm birch plywood
• Enclosure finish: Black Water-based paint
• Grille: Black steel grille, acoustically transparent fabric
• Dimensions: 282 x 689 x 406 mm
• Weight: 28 kg
• Frequency response: 60 - 20,000 Hz (±10 dB), 70 Hz - 18,000 (±3 dB)
• Sensitivity: 104 dB
• Coverage angle: 100° x 10°
• Nominal impedance: 8 ohms
• Sound pressure level SPL: 132 dB, 138 dB peak
• Drivers: LF: 2x9" 65 mm voice coil, ferrite magnet HF: 1x3" 75 mm voice coil, neodymium compression magnet
• Connection method: Full Range, 2xNeutrik NL4x2 / 1+1-
• Nominal power: 800 W (AES)
• Enclosure: 15 mm birch plywood
• Enclosure finish: Black Water-based paint
• Grille: Black steel grille, acoustically transparent fabric
• Dimensions: 282 x 689 x 406 mm
• Weight: 28 kg
