KEY FEATURES
• Type: Power amplifier with built-in DSP
• Filters: 10-band IIR filters, FIR filter
• Outputs: 4 analog outputs
• Power per channel, W/8 ohms: 4x1300 W RMS
• Power per channel, W/4 ohms: 4x2200 W RMS
• Power per channel, W/2 ohms: 4x2000 W RMS
• Inputs: 4 analog XLR inputs, 2 AES/EBU inputs (AES3), 2 LAN 1 Gbps RJ-45 inputs
• Maximum power consumption: 2500 W
• Amplifier class: Class D
• Power supply model: Switched-mode universal power supply (SMPS) with power factor correction (PFC)
• Nominal line voltage: 100-240 V ~ ±10%, 50-60 Hz
• Requirements for the nominal Current: 16 A for 200-240 V
• DSP: SHARC 32-bit floating point, 96 kHz sampling rate
• Number of presets: 24.0
• ADC dynamic range: 122 dBA
• DAC dynamic range: 123 dBA
• Dimensions: 483 x 360 x 88 mm
• Weight: 12.3 kg
• Filters: 10-band IIR filters, FIR filter
• Outputs: 4 analog outputs
• Power per channel, W/8 ohms: 4x1300 W RMS
• Power per channel, W/4 ohms: 4x2200 W RMS
• Power per channel, W/2 ohms: 4x2000 W RMS
• Inputs: 4 analog XLR inputs, 2 AES/EBU inputs (AES3), 2 LAN 1 Gbps RJ-45 inputs
• Maximum power consumption: 2500 W
• Amplifier class: Class D
• Power supply model: Switched-mode universal power supply (SMPS) with power factor correction (PFC)
• Nominal line voltage: 100-240 V ~ ±10%, 50-60 Hz
• Requirements for the nominal Current: 16 A for 200-240 V
• DSP: SHARC 32-bit floating point, 96 kHz sampling rate
• Number of presets: 24.0
• ADC dynamic range: 122 dBA
• DAC dynamic range: 123 dBA
• Dimensions: 483 x 360 x 88 mm
• Weight: 12.3 kg
