KEY FEATURES
• Type: Line array element
• Frequency range: 35 - 20,000 Hz (±10 dB), 40 Hz - 18,000 (±3 dB)
• Sensitivity: LF-L: 98 dB, LF-R: 98 dB, MF: 107 dB, HF: 114 dB
• Coverage angle: 70° x 10°
• Nominal impedance: LF-L: 8 ohms, LF-R: 8 ohms, MF: 8 ohms, HF: 16 ohms
• Sound pressure level (SPL): LF-L: 125 dB, 131 dB peak, LF-R: 125 dB, 131 dB peak, MF: 134 dB, 140 dB peak, HF: 137 dB, 143 dB peak
• Drivers: LF-L: 1x12" 75mm voice coil, LF-R: 1x12" 75mm voice coil, MF: 4x6.5" 38mm voice coil, HF: 2x3" 75mm voice coil, neodymium magnet
• Connection method: Q-Amp, LF-L: 1+1, LF-R: 2+2, MF: 3+3, HF: 4+4
• Nominal power: LF-L: 500 W, LF-R: 500 W, MF: 480 W, HF: 180 W
• Enclosure: 18 mm birch plywood
• Enclosure finish: Black polyurethane paint
• Grille: Black polyurethane paint
• Dimensions: 361x1180x540 mm
• Weight: 71 kg
• Frequency range: 35 - 20,000 Hz (±10 dB), 40 Hz - 18,000 (±3 dB)
• Sensitivity: LF-L: 98 dB, LF-R: 98 dB, MF: 107 dB, HF: 114 dB
• Coverage angle: 70° x 10°
• Nominal impedance: LF-L: 8 ohms, LF-R: 8 ohms, MF: 8 ohms, HF: 16 ohms
• Sound pressure level (SPL): LF-L: 125 dB, 131 dB peak, LF-R: 125 dB, 131 dB peak, MF: 134 dB, 140 dB peak, HF: 137 dB, 143 dB peak
• Drivers: LF-L: 1x12" 75mm voice coil, LF-R: 1x12" 75mm voice coil, MF: 4x6.5" 38mm voice coil, HF: 2x3" 75mm voice coil, neodymium magnet
• Connection method: Q-Amp, LF-L: 1+1, LF-R: 2+2, MF: 3+3, HF: 4+4
• Nominal power: LF-L: 500 W, LF-R: 500 W, MF: 480 W, HF: 180 W
• Enclosure: 18 mm birch plywood
• Enclosure finish: Black polyurethane paint
• Grille: Black polyurethane paint
• Dimensions: 361x1180x540 mm
• Weight: 71 kg
